Monitored Electric Lock AHM-ML350
A monitored electric lock suitable for FD30 and FD60 fire doors.
- Operating voltage: 12 VDC (24Vdc available to order)
- Voltage tolerance: ±10%
- Current draw: 280mA/12VDC; 140mA/24VDC
- Operating temperature: -10-45°C (14 to 131°F)
- Lock’s surface temperature: Current temperature ±20% (when power is on)
- Humidity: 0-95% non-condensing
- Solenoid testing: tested to over 250,000 cycles
- Preload: 500 lbs of pressure strength
- Holding force: 1500 lbs
- Finish: Stainless steel
- Surface/glass mount brackets: anodized aluminum finish
- Net weight: ML-350M: 673g (approx)
- Applicable to horizontal or vertical installations
- Locking mode: Fail-safe locked
- Fire resistance test conducted in accordance with BS EN 1634-1: 2014 and BS EN 1363-1: 2012 (for ML-350M)
Compatible with the following ranges
- Education Range
- Healthcare Range
- Hotel & Hospitality Collection
- Social Housing Range
- Quick Service Door Range
- Mercantile Range (Commercial)
- PAS24 Secured By Design
- Artisan Panel Door Collection
- Airport Range
Finish options
- Stainless Steel
Disclaimer: Ironmongery finishes can vary by brand, manufacturer and the base metal they are applied to. These colour samples are for guidance purposes only and may differ from the actual finish.
